Magnetic guide for cutting dovetail joints with interchangeable tips (90°, 45°, 1:4, 1:5, 1:6, 1:7, 1:8, 1:9)

A simple, effective guide with interchangeable tips for precise dovetail joint cutting.

The device is mounted on the workpiece and secured with a brass clamp. Magnetic tips are inserted into the construction, guiding the hand saw at the selected angle.

Features:

• aluminum clamp construction with brass knob;
• wide range of tips for cutting in various proportions: 90°, 45°, 1:4, 1:5, 1:6, 1:7, 1:8, 1:9;
• ability to mount tips on both sides of the guide and rotate in any direction;
• tips made of durable material and equipped with magnets for precise saw guidance;

The guide is dedicated to creating dovetail joints in the proportions of 1:4, 1:5, 1:6, 1:7, 1:8, 1:9, and for cutting at angles of 90 and 45 degrees.

Parameters:

• maximum thickness of the material being cut: 25mm
• minimum thickness of the material: 6mm
• total height of the guide body: 72mm
• width of the guide body: 42mm
• surface area of interchangeable tips: 40x40mm

Link to the product video: https://youtube.com/shorts/lqPkFlOmYb4
